FluoSolv®
FluoSolv® 7100DL High-Purity Precision Cleaning Fluid
No reviews yet
Write a Review
Write a Review
FluoSolv®
FluoSolv® 7100DL High-Purity Precision Cleaning Fluid
Ultra-HighPurity ≤1 ppm non-volatile residue(NVR) Broad MaterialCompatibility Compatible with a wide variety ofmetals, plastics, and elastomers ExceptionalWetting Low surface tensionand viscosity Nonflammable&am…
$100.00
Product Details
Ultra-High
Broad Material
Exceptional
Nonflammable
High-Reliability
Hard Disk Drive Manufacturing
High-Reliability Precision Cleaning
Lubricant & Additive Deposition
Aerospace & Defense Components
Electronics & Semiconductor Manufacturing
Medical Device Component Cleaning
Ultra-High
Broad Material
Exceptional
Nonflammable
High-Reliability
Need Help Selecting
Ultra-High
Purity
≤1 ppm non-volatile residue
(NVR)
Broad Material
Compatibility
Compatible with a wide variety of
metals, plastics, and elastomers
Exceptional
Wetting
Low surface tension
and viscosity
Nonflammable
& Stable
Thermally and chemically stable for
consistent process performance
High-Reliability
Manufacturing
Designed for precision
applications
About FluoSolv® 7100DL
FluoSolv® 7100DL is a clear, colorless, ultra-high-purity hydrofluoroether (HFE) engineered as a direct, drop-in replacement for 3M™ Novec™ 7100DL Engineered Fluid. Designed for applications requiring exceptional contamination control, FluoSolv® 7100DL provides tightly controlled levels of ions, metals, particulates, and non-volatile residue (≤1 ppm NVR) for precision cleaning, lubricant deposition, and high-reliability manufacturing.
With low surface tension, low viscosity, excellent materials compatibility, and nonflammable performance, FluoSolv® 7100DL provides exceptional wetting, rinsing, and penetration into micro-features and complex geometries. It is particularly well suited for hard disk drive, electronics, semiconductor, aerospace, medical device, and other critical applications where product purity and minimal residue are essential.
Contact NuGenTec technical experts for assistance evaluating FluoSolv® 7100DL as a replacement for 3M™ Novec™ 7100DL in your specific process.
Typical Applications
Hard Disk Drive Manufacturing High-Reliability Precision Cleaning Lubricant & Additive Deposition Aerospace & Defense Components Electronics & Semiconductor Manufacturing Medical Device Component Cleaning
Ultra-High
Purity
≤1 ppm non-volatile residue
(NVR)
Broad Material
Compatibility
Compatible with a wide variety of
metals, plastics, and elastomers
Exceptional
Wetting
Low surface tension
and viscosity
Nonflammable
& Stable
Thermally and chemically stable for
consistent process performance
High-Reliability
Manufacturing
Designed for precision
applications
Typical Properties
| Property | FluoSolv® 7100DL |
|---|---|
| Boiling Point, °C (°F) | 61.0 (141.8) |
| Density at 25°C (77°F), g/mls (lbs/gal) | 1.520 (12.68) |
| Flash Point, °C (°F) | None to Boiling Point |
| Surface Tension at 25°C (77°F), dynes/cm | 13.6 |
| Viscosity at 25°C (77°F), cPs | 0.58 |
| Vapor Pressure at 25°C (77°F), kPa | 26.9 |
| Heat of Vaporization at B.P. (kJ/kg) | 112 |
| Global Warming Potential (GWP), /100 year ITH | 320 |
| Ozone Depletion Potential (ODP), CFC-11 = 1.0 | 0 |
| Volatile Organic Compounds (VOC), g/L | 0 |
| Kauri-Butanol Value (KB Value) | 10 |
| Acceptable Exposure Limit (AEL), ppm | 750 |
Process Parameters
| Parameter | Typical Operating Range |
|---|---|
| Boil Sump Temperature, °C (°F) | 61.0 (141.8) |
| Primary Cooling Coil Temperature, °C (°F) | 4.0–10.0 (39.2–50.0) |
| Secondary (Sub-Zero) Coil Temperature, °C (°F) | −20.0 to −30.0 (−4.0 to −22.0) |
| Immersion Sump Temperature, °C (°F) | 46.0–56.0 (114.8–132.8) |
| Ultrasonic Frequency, kHz | 20.0–40.0 |
| Dwell Time in Vapor | 30 sec–2 min, or until condensation ceases |
| Immersion Time | 1–8 min; adjust for soil, geometry, and cleanliness requirement |
| Hoist Speed, m/min (ft/min) | ≤3.4 (11.2); slower withdrawal may reduce solvent carryout |
| Freeboard Ratio, minimum | ≥0.75 (1.00–1.25); preferred for improved vapor containment |
Material Compatibility
| Material | Compatibility |
|---|---|
| Aluminum | Compatible |
| Copper | Compatible |
| Stainless Steel | Compatible |
| Titanium | Compatible |
| Brass | Compatible |
| Tungsten | Compatible |
| Neoprene | Compatible |
| Butyl Rubber | Compatible |
| EPDM | Compatible |
| KYNAR (PVDF) | Compatible |
| Viton A&B | Test for Compatibility |
| Kalrez | Test for Compatibility |
| HDPE | Compatible |
| PTFE | Test for Compatibility |
| Nylon | Compatible |
| PVC | Compatible |
| Epoxy | Compatible |
| Phenolic | Compatible |
| ABS | Test for Compatibility |
| Acrylic | Test for Compatibility |
| Polycarbonate | Test for Compatibility |
| Other Metals, Elastomers, Plastics | Test for Compatibility |
Available Sizes
| Package Size (Volume) | Package Size (Net Weight) |
|---|---|
| 55-gallon lined metal drums | 550 lbs |
| 5-gallon lined pails | 52.5 lbs |
