FluoSolv® 7100 Vapor Degreasing & Precision Cleaning Fluid
No reviews yet
Write a Review
Write a Review
FluoSolv®
FluoSolv® 7100 Vapor Degreasing & Precision Cleaning Fluid
Precision CleaningPerformance Removes light oils, fluorolubes,and particulates Broad MaterialCompatibility Compatible with a wide variety ofmetals, plastics, and elastomers Zero Ozone DepletionPotential Environmental…
$100.00
Product Details
Precision Cleaning
Broad Material
Zero Ozone Depletion
Low Atmospheric
Low Surface
Vapor Degreasing
Precision Cleaning of Metal Components
Electronics Manufacturing
Medical Device Cleaning
Aerospace & Defense Components
Rinsing & Spot-Free Drying
Precision Cleaning
Broad Material
Zero Ozone Depletion
Low Atmospheric
Low Surface
Need Help Selecting
Precision Cleaning
Performance
Removes light oils, fluorolubes,
and particulates
Broad Material
Compatibility
Compatible with a wide variety of
metals, plastics, and elastomers
Zero Ozone Depletion
Potential
Environmentally responsible
fluorinated solvent
Low Atmospheric
Lifetime
Rapid atmospheric degradation
Low Surface
Tension
Excellent wetting, rinsing, and
penetration into complex geometries
About FluoSolv® 7100
FluoSolv® 7100 is a clear, colorless, low-odor hydrofluoroether (HFE) engineered as a direct, drop-in replacement for 3M™ Novec™ 7100 Engineered Fluid. With zero Ozone Depletion Potential (ODP), low surface tension, excellent materials compatibility, and a 750 ppm time-weighted average exposure guideline, FluoSolv® 7100 provides a versatile solution for precision cleaning, vapor degreasing, rinsing, drying, and specialty solvent applications.
FluoSolv® 7100 can be used neat, as an azeotropic component, or in co-solvent cleaning processes for removal of light oils, fluorolubes, particulates, and other light-duty contaminants. Its chemical and thermal stability, nonflammability, and excellent wetting characteristics also make it suitable for lubricant carrying, spot-free rinsing and drying, spray contact cleaning, dielectric testing, dispersion and reaction media, and heat-transfer applications.
Contact NuGenTec technical experts for assistance evaluating FluoSolv® 7100 as a replacement for 3M™ Novec™ 7100 in your specific application.
Typical Applications
Vapor Degreasing Precision Cleaning of Metal Components Electronics Manufacturing Medical Device Cleaning Aerospace & Defense Components Rinsing & Spot-Free Drying
Precision Cleaning
Performance
Removes light oils, fluorolubes,
and particulates
Broad Material
Compatibility
Compatible with a wide variety of
metals, plastics, and elastomers
Zero Ozone Depletion
Potential
Environmentally responsible
fluorinated solvent
Low Atmospheric
Lifetime
Rapid atmospheric degradation
Low Surface
Tension
Excellent wetting, rinsing, and
penetration into complex geometries
Typical Properties
| Property | FluoSolv® 7100 |
|---|---|
| Boiling Point, °C (°F) | 61.0 (141.8) |
| Density at 25°C (77°F), g/mls (lbs/gal) | 1.520 (12.68) |
| Flash Point, °C (°F) | None to Boiling Point |
| Surface Tension at 25°C (77°F), dynes/cm | 13.6 |
| Viscosity at 25°C (77°F), cPs | 0.58 |
| Vapor Pressure at 25°C (77°F), kPa | 26.9 |
| Heat of Vaporization at B.P. (kJ/kg) | 112 |
| Global Warming Potential (GWP), /100 year ITH | 320 |
| Ozone Depletion Potential (ODP), CFC-11 = 1.0 | 0 |
| Volatile Organic Compounds (VOC), g/L | 0 |
| Kauri-Butanol Value (KB Value) | 10 |
| Acceptable Exposure Limit (AEL), ppm | 750 |
Process Parameters
| Parameter | Typical Operating Range |
|---|---|
| Boil Sump Temperature, °C (°F) | 61.0 (141.8) |
| Primary Cooling Coil Temperature, °C (°F) | 4.0–10.0 (39.2–50.0) |
| Secondary (Sub-Zero) Coil Temperature, °C (°F) | −20.0 to −30.0 (−4.0 to −22.0) |
| Immersion Sump Temperature, °C (°F) | 46.0–56.0 (114.8–132.8) |
| Ultrasonic Frequency, kHz | 20.0–40.0 |
| Dwell Time in Vapor | 30 sec–2 min, or until condensation ceases |
| Immersion Time | 1–8 min; adjust for soil, geometry, and cleanliness requirement |
| Hoist Speed, m/min (ft/min) | ≤3.4 (11.2); slower withdrawal may reduce solvent carryout |
| Freeboard Ratio, minimum | ≥0.75 (1.00–1.25); preferred for improved vapor containment |
Material Compatibility
| Material | Compatibility |
|---|---|
| Aluminum | Compatible |
| Copper | Compatible |
| Stainless Steel | Compatible |
| Titanium | Compatible |
| Brass | Compatible |
| Tungsten | Compatible |
| Neoprene | Compatible |
| Butyl Rubber | Compatible |
| EPDM | Compatible |
| KYNAR (PVDF) | Compatible |
| Viton A&B | Test for Compatibility |
| Kalrez | Test for Compatibility |
| HDPE | Compatible |
| PTFE | Test for Compatibility |
| Nylon | Compatible |
| PVC | Compatible |
| Epoxy | Compatible |
| Phenolic | Compatible |
| ABS | Test for Compatibility |
| Acrylic | Test for Compatibility |
| Polycarbonate | Test for Compatibility |
| Other Metals, Elastomers, Plastics | Test for Compatibility |
Available Sizes
| Package Size (Volume) | Package Size (Net Weight) |
|---|---|
| 55-gallon lined metal drums | 550 lbs |
| 5-gallon lined pails | 52.5 lbs |
