FluoSolv®
FluoSolv® PF-5052 Dielectric Heat Transfer Fluid
No reviews yet
Write a Review
Write a Review
FluoSolv®
FluoSolv® PF-5052 Dielectric Heat Transfer Fluid
Precision Thermal Control Stable fluorinated chemistry for demanding electronics thermal-management systems Low Viscosity Promotes efficient circulation and heat transfer through complex component geometries Nonflamm…
$100.00
Product Details
Precision Thermal Control
Stable fluorinated chemistry for demanding electronics thermal-management systems
Low Viscosity
Promotes efficient circulation and heat transfer through complex component geometries
Nonflammable
No flash point for use around sensitive electronic and electrical equipment
Excellent Dielectric Strength
Electrically insulating fluid for direct-contact cooling of energized components
Thermally Stable
Chemically and thermally stable for demanding heat-transfer applications
ABOUT FLUOSOLV® PF-5052
FluoSolv® PF-5052 is a high-performance perfluorinated dielectric heat-transfer fluid engineered as a direct, drop-in replacement for 3M™ Performance Fluid PF-5052. Designed for demanding electronics and thermal-management applications, FluoSolv® PF-5052 combines excellent dielectric strength, low viscosity, nonflammability, chemical inertness, and thermal stability for reliable heat transfer around sensitive electrical and electronic components.
Its electrically insulating properties make FluoSolv® PF-5052 particularly well suited for direct-contact electronics cooling, semiconductor process equipment, electronic testing, power electronics, and other systems where the heat-transfer fluid may contact energized components. Its low viscosity promotes circulation through complex geometries while its fluorinated chemistry provides excellent chemical stability and broad compatibility with commonly used system materials.
Contact NuGenTec technical experts for assistance evaluating FluoSolv® PF-5052 as a replacement for 3M™ Performance Fluid PF-5052 or Fluorinert™ FC-3283 in your electronics-cooling, semiconductor, testing, or advanced thermal-management system.
TYPICAL APPLICATIONS
Dielectric Heat Transfer
Electronic & Reliability Testing
Semiconductor Process Equipment
Power Electronics Cooling
Direct-Contact Electronics Cooling
Low-Temperature Thermal Control
Precision Thermal Control
Stable fluorinated chemistry for demanding electronics thermal-management systems
Low Viscosity
Promotes efficient circulation and heat transfer through complex component geometries
Nonflammable
No flash point for use around sensitive electronic and electrical equipment
Excellent Dielectric Strength
Electrically insulating fluid for direct-contact cooling of energized components
Thermally Stable
Chemically and thermally stable for demanding heat-transfer applications
TYPICAL PROPERTIES
| Property | FluoSolv® PF-5052 |
|---|---|
| Boiling Point, °C (°F) | 128.0 (262.4) |
| Pour Point, °C (°F) | −50.0 (−58.0) |
| Density at 25°C (77°F), g/mL (lb/gal) | 1.820 (15.19) |
| Flash Point, °C (°F) | None |
| Viscosity at 25°C (77°F), mPa·s | 1.4 |
| Vapor Pressure at 25°C (77°F), kPa | 1.87 |
| Thermal Conductivity at 25°C (77°F), W/m·K | 0.066 |
| Specific Heat at 25°C (77°F), kJ/kg·K | 1.1 |
| Heat of Vaporization at B.P., kJ/kg | 82 |
| Dielectric Strength, 0.1-in gap, kV | >40 |
| Dielectric Constant at 1 kHz | 1.9 |
| Volume Resistivity, Ω·cm | 2 × 1015 |
MATERIAL COMPATIBILITY — METALS
| Material | Compatibility |
|---|---|
| Aluminum | Compatible |
| Cast Steel | Compatible |
| Monel | Compatible |
| Brass | Compatible |
| Copper | Compatible |
| Nickel | Compatible |
| Bronze | Compatible |
| Hastelloy | Compatible |
| Stainless Steel | Compatible |
| Carbon Steel | Compatible |
| Inconel | Compatible |
| Tantalum | Compatible |
| Cast Iron | Compatible |
| Incoloy 825 | Compatible |
| Titanium | Compatible |
| Ti6Al4V | Compatible |
| Zinc | Testing Recommended |
| Zinc Plating | Testing Recommended |
| Galvanized Surfaces | Testing Recommended |
| Magnesium | Testing Recommended |
| Other Metals | Testing Recommended |
MATERIAL COMPATIBILITY — GASKETS & POLYMERS
| Material | Compatibility |
|---|---|
| Nitrile / NBR | Testing Recommended |
| Hydrogenated Nitrile / HNBR | Testing Recommended |
| EP / EPDM | Compatible |
| Chloroprene | Testing Recommended |
| Isobutylene / IIR Latex | Compatible |
| Synthetic Isoprene / NR (Natural Rubber) | Testing Recommended |
| Natural Isoprene / NR (Natural Rubber) | Testing Recommended |
| Fluorosilicone | Testing Recommended |
| Fluorocarbon / FKM (Viton) | Testing Recommended |
| Chemraz Kalrez / FFKM | Testing Recommended |
| PTFE / FEP (Teflon) | Compatible |
| Gylon Style 3500, 3504, 3510 | Compatible |
| Nylon / Polyamide | Testing Recommended |
| Polyvinyl Chloride / PVC | Testing Recommended |
| Polyethylene | Compatible |
| Polypropylene | Compatible |
| Epoxy | Compatible |
| Graphite | Compatible |
| Other Gaskets & Polymers | Testing Recommended |
AVAILABLE SIZES
| Package Size | Net Weight |
|---|---|
| 55-gallon lined metal drums | 550 lb |
| 5-gallon lined pails | 52.5 lb |
