NuTherm® PF-50 Potassium Formate Heat Transfer Fluid
No reviews yet
Write a Review
Write a Review
NuTherm
NuTherm® PF-50 Potassium Formate Heat Transfer Fluid
High Heat-Transfer Efficiency High thermal conductivity and specific heat for efficient thermal transfer Low Viscosity Reduces pumping resistance compared with conventional glycol fluids Nonflammable No flash point f…
$100.00
Product Details
Open Bath Heat Transfer
Low-Temperature Refrigeration
Aerospace Component Testing
Environmental & Thermal Test Systems
Industrial Process Cooling
Process Temperature Control
High Heat-Transfer Efficiency
High thermal conductivity and specific heat for efficient thermal transfer
Low Viscosity
Reduces pumping resistance compared with conventional glycol fluids
Nonflammable
No flash point for improved system and facility safety
Robust Corrosion Protection
Inhibited for use with a broad range of common system metals
Biodegradable & Zero VOC
Water-based, CFC-free formulation with 0 g/L VOC
About NuTherm® PF-50
NuTherm® PF-50 is a high-performance potassium formate/water heat-transfer fluid engineered specifically for open-bath systems requiring exceptional low-temperature performance and efficient thermal transfer. Designed for open-bath operation from −51°C to +110°C (−60°F to +230°F), NuTherm® PF-50 combines high thermal conductivity, high specific heat and low viscosity to provide an efficient alternative to conventional glycol, PAG and calcium chloride open-bath heat-transfer fluids.
NuTherm® PF-50 is nonflammable, biodegradable, CFC-free and formulated with a robust corrosion-inhibition package for use with a broad range of compatible metals and polymers. Its low viscosity helps reduce pumping resistance while its favorable thermophysical properties promote efficient temperature control in demanding low-temperature baths, process-cooling equipment, environmental and thermal testing systems, and other open-bath thermal-management applications.
Contact NuGenTec technical experts for assistance evaluating NuTherm® PF-50 for your open-bath heat-transfer, low-temperature process-cooling, testing, or temperature-control system.
Typical Applications
Open Bath Heat Transfer Low-Temperature Refrigeration Aerospace Component Testing Environmental & Thermal Test Systems Industrial Process Cooling Process Temperature Control
High Heat-Transfer Efficiency
High thermal conductivity and specific heat for efficient thermal transfer
Low Viscosity
Reduces pumping resistance compared with conventional glycol fluids
Nonflammable
No flash point for improved system and facility safety
Robust Corrosion Protection
Inhibited for use with a broad range of common system metals
Biodegradable & Zero VOC
Water-based, CFC-free formulation with 0 g/L VOC
Typical Properties
| Property | NuTherm® PF-50 |
|---|---|
| Boiling Point, °C (°F) | 118.0 (244.4) |
| Freezing Point, °C (°F) | −55.0 (−67.0) |
| Density at 20°C (68°F), g/ml (lb/gal) | 1.341 (11.19) |
| pH, 100% | 8.00–8.50 |
| Flash Point, °C (°F) | None |
| Viscosity at 20°C (68°F), mPa·s | 3.20 |
| Vapor Pressure at 20°C (68°F), psia | 0.23 |
| Thermal Conductivity at 20°C (68°F), W/m·K | 0.505 |
| Specific Heat at 20°C (68°F), kJ/kg·K | 2.701 |
| Operating Temperature Range, °C (°F) | −51.0 to 110.0 (−60.0 to 230.0) |
| Volatile Organic Compounds (VOC), g/L | 0 |
| Acceptable Exposure Limit (AEL), ppm | No exposure limit |
Material Compatibility: Metals
| Material | Compatibility |
|---|---|
| Aluminum* | Compatible, Contact Technical Expert |
| Cast Steel | Compatible |
| Monel | Compatible |
| Brass | Compatible |
| Copper | Compatible |
| Nickel | Compatible |
| Bronze | Compatible |
| Hastelloy | Compatible |
| Stainless Steel | Compatible |
| Carbon Steel | Compatible |
| Inconel | Compatible |
| Tantalum | Compatible |
| Cast Iron | Compatible, Contact Technical Expert |
| Incoloy 825 | Compatible |
| Titanium | Compatible |
| Ti6Al4V | Compatible |
| Zinc** | Incompatible, Contact Technical Expert |
| Zinc Plating** | Incompatible, Contact Technical Expert |
| Galvanized Surfaces** | Incompatible, Contact Technical Expert |
| Magnesium** | Incompatible, Contact Technical Expert |
| Other Metals | Testing Recommended |
Material Compatibility: Gaskets & Polymers
| Material | Compatibility |
|---|---|
| Nitrile / NBR | Excellent to 65.6°C (150.0°F), Good Above 65.6°C (150.0°F) |
| Hydrogenated Nitrile / HNBR | Excellent |
| EP, EPDM | Excellent |
| Chloropropene | Good |
| Isobutylene / IIR Latex | Good |
| Synthetic Isoprene / NR (Natural Rubber) | Good / Excellent |
| Natural Isoprene / NR (Natural Rubber) | Good / Excellent |
| Fluorosilicone | Good / Excellent |
| Fluorocarbon / FKM (Viton) | Good to 37.8°C (100.0°F), Poor Above 37.8°C (100.0°F) |
| Chemraz Kalrez / FFKM | Excellent |
| PTFE / FEP (Teflon) | Excellent |
| Gylon Stylve 3500, 3504, 3510 | Excellent |
| Nylon / Polyamide | Good / Excellent |
| Polyvinyl Chloride / PVC | Good / Excellent |
| Polyethylene | Excellent |
| Polypropylene | Excellent |
| Epoxy | Good / Excellent |
| Graphite | Excellent |
| Other Gaskets & Polymers | Testing Recommended |
Available Sizes
| Package Size | Net Weight |
|---|---|
| 275-gallon plastic totes | 3,077 lbs |
| 55-gallon plastic drums | 615 lbs |
| 5-gallon plastic pails | 56.0 lbs |
