Heat Transfer Fluids

NuTherm™ Heat Transfer Fluids

The NuTherm PF and HC series are a high-performance set of heat transfer fluids designed as an alternative to less effective glycol, PAG, and Calcium Chloride fluids. They are non-toxic, non-flammable, and have a robust corrosion inhibition package making them ideal for use.

Features

• To the best of our knowledge, this product is California Prop 65 compliant.
• High thermal conductivity
• High specific heat
• Low viscosity
• Non-toxic, non-flammable
• High metal compatibility
• Biodegradable
• Environmentally friendly (CFC-free)
• Robust corrosion inhibition
• Economical
• Pre-mixed solutions

Thermophysical properties of NuTherm HC & PF

The NuTherm HC & PF series has superior thermophysical properties in comparison to traditional closed and open system heat transfer fluids, including higher thermal conductivity and specific heat, as well as lower viscosity, making it an extraordinarily more efficient system coolant within its operational temperature range. The NuTherm HC series is non-hazardous, biodegradable, CFC-free, antimicrobial, and has exceptional thermal stability at high temperatures in comparison to glycols, PAG’s, Calcium Chloride, Trichloroethylene and Methylene Chloride (Dichloromethane) making it an intelligent alternative.

Heat Transfer Fluids Resistant to Corrosion

The NuTherm PF and HC series is formulated with an incredibly robust and efficient corrosion inhibition package, allowing the product to be used on most metals including Stainless Steel, Carbon Steel, Cast Steel, Copper and its alloys (Brass & Bronze), Monel, Nickel, Hastelloy, Inconel, Tantalum, Titanium, Titanium alloys (Ti6Al4V), Aluminium and Cast Iron. Do not use on Zinc, Zinc-plated or galvanized metals, Magnesium. NuTherm PF and HC corrosion tests at 80 °C show incredible results of x mmpy (x mpy) on C260 Brass alloys, x mmpy (x mpy) on 304L Stainless Steel, and x mmpy (x mpy) on AL1100 Aluminium.

NuThem PF and HC does not produce pitting corrosion on Aluminium alloys like other Potassium Formate open or closed bath heat transfer fluids.

*mmpy = millimeters per year; mpy = mils per year (1 mil = 0.001 inch); In general, uniform corrosion rates less than 2 mpy are acceptable for most applications. Corrosion rates between 2 and 10 mpy are considered marginal and may impact useful life of the equipment. Corrosion rates greater than 10 mpy per year are unacceptable.

• Availability: 5-gallon pails, 55-gallon drums, 275-gallon tote-bins, and bulk tankers.
• Shipment: Non-Hazardous for transport via DOT, IMDG, and IATA.
• Storage: Keep out of direct sunlight. Keep from freezing. Store between 4 to 38°F (40-100°F).
• Disposal: Dispose of in accordance with local, state, and federal regulations.



EMERGENCY OVERVIEW:

This product may cause serious irritation to the eyes.

SAFETY:

Please make sure you have read and understood the product label and SDS before using this product. Use proper chemical hygiene when handling this product. Wash thoroughly after handling. Observe label precautions. This product is classified and labeled according to the Globally Harmonized System (GHS).
