FluoSolv® 7100DL

Download TDS:

• FluoSolv® 7100DL-3M-Novec-7100DL-Replacement-Fluid-TDS

Download MSDS:

• FluoSolv® 7100DL-US-EN-2-sds

Introduction

FluoSolv® 7100DL is a clear, colorless, ultra-high-purity hydrofluoroether (HFE), engineered as an exact replacement for 3M Novec 7100DL. It matches Novec 7100DL in ion, metal, particulate, and non-volatile residue control (1 ppm NVR) and is optimized for electronics manufacturing, precision cleaning, and lubricant deposition. The fluid is non-flammable, non-conductive, VOC-exempt in the U.S., non-ozone-depleting, low in toxicity, and thermally stable.

Key Features & Benefits

Ultra‑high purity: ≤ 1 ppm non‑volatile residue; tightly controlled limits on ions, metals, and particulates

Exceptional solvent performance: low surface tension (~13.6 mN/m) and low viscosity (~0.38 cSt at 25 °C) enable excellent wetting, rinsing, and cleaning of micro‑features

Safe and stable: non‑flammable, thermally/chemically stable, VOC‑exempt under U.S. EPA rules

Low toxicity: practically non‑toxic via inhalation or oral exposure, with an occupational exposure guideline of 750 ppm (8‑hour TWA)

Environmentally responsible: zero Ozone Depletion Potential (ODP = 0), low Global Warming Potential (~297), and short atmospheric lifetime (~3.8–4.1 years)

Applications

FluoSolv® 7100DL is tailored for high-purity electronics and industrial uses, including:

• Hard disk drive media lubrication: deposition of fluorinated lubricants onto media surfaces and processing of head gimbal assemblies
• Precision cleaning: removal of particulates, flux residues, and specialty contaminants in semiconductor and aerospace manufacturing
• Deposition solvent: for coating and manufacturing applications requiring strict contaminant control
• High reliability manufacturing: use in environments where material purity and minimal residues are essential

Material Compatibility

FluoSolv® 7100DL is compatible with a wide variety of metals, plastics, and elastomers, as documented from equivalence with Novec 7100DL:

• Metals: aluminum, copper (may exhibit slight oxidation), carbon steel, stainless steel (AISI 300), brass, molybdenum, tantalum, tungsten, Cu/Be alloy (C172), Mg‑alloy AZ32B
• Plastics: acrylic (PMMA), polyethylene, polypropylene, PET, epoxy, polyester, polycarbonate, ABS, phenolic
• Elastomers: EPDM, EPR (nitrile), butyl rubber (preferred for long exposure), natural rubber; note that silicone, PTFE, FFKM/FKM may absorb and swell over time

Physical Properties

Features

To the best of our knowledge, this product is California Prop 65 compliant.

Free Solvent Sample and Vapor Degreaser for Testing

NuGenTec offers a small loaner vapor degreaser and a loaner 5-gallon pail to assist with your testing. The loaner vapor degreaser plugs into a standard wall outlet and fits on a standard pallet. This allows you to test our FluoSolv® solvent in your own controlled environment without immediately changing the solvent in your current equipment.

FluoSolv® 7100DL is available for purchase in three package sizes:

• 55-gal phenolic lined metal drums
• 5-gal phenolic lined pails
• 1-gal HDPE plastic bottles

For more information about testing our FluoSolv® 7100DL, please call us at 800-409-3142 or Contact Us.

Email: FluoSolv@nugentec.com
