Ethylene Glycol
Efficient Heat Transfer Excellent thermal performance for industrial heating and cooling systems Lower Viscosity Lower viscosity than comparable propylene glycol solutions for improved pumpability Long Service Life I…
$100.00
Product Details
Closed-Loop Heat Transfer
Data Center Secondary Cooling
Refrigeration & Freeze Protection
HVAC & Chilled-Water Systems
Industrial Process Cooling & Heating
Process Temperature Control
Efficient Heat Transfer
Excellent thermal performance for industrial heating and cooling systems
Lower Viscosity
Lower viscosity than comparable propylene glycol solutions for improved pumpability
Long Service Life
Inhibitor package helps maintain pH stability and protect system components
Corrosion Protection
Inhibited for protection of common metals in properly maintained systems
Proven Technology
Widely used for industrial HVAC, refrigeration and process heat transfer
About Ethylene Glycol
NuGenTec inhibited Ethylene Glycol is a high-performance glycol-based heat-transfer fluid designed for closed-loop heating, cooling, refrigeration, HVAC, and industrial process applications. When blended with deionized water at the appropriate concentration, ethylene glycol provides reliable freeze and burst protection while maintaining excellent heat-transfer performance and lower viscosity than comparable propylene glycol solutions.
The fluid is formulated with corrosion inhibitors to help protect common system metals and maintain stable performance throughout extended service. Ethylene glycol/water concentration can be selected based on the required freeze protection, operating temperature, and thermal-performance requirements, allowing the fluid to be optimized for applications ranging from HVAC and process cooling to industrial refrigeration, ice rinks, snow-melt systems, and other closed-loop thermal-management systems.
Contact NuGenTec technical experts for assistance selecting the appropriate ethylene glycol concentration and evaluating compatibility, freeze protection, and thermal performance for your heat-transfer system.
Typical Applications
Closed-Loop Heat Transfer Data Center Secondary Cooling Refrigeration & Freeze Protection HVAC & Chilled-Water Systems Industrial Process Cooling & Heating Process Temperature Control
Efficient Heat Transfer
Excellent thermal performance for industrial heating and cooling systems
Lower Viscosity
Lower viscosity than comparable propylene glycol solutions for improved pumpability
Long Service Life
Inhibitor package helps maintain pH stability and protect system components
Corrosion Protection
Inhibited for protection of common metals in properly maintained systems
Proven Technology
Widely used for industrial HVAC, refrigeration and process heat transfer
Typical Properties
| Property | Ethylene Glycol |
|---|---|
| Boiling Point, °C (°F) | Concentration dependent, typically 100.0 to 158.3 (212.0 to 317.0) |
| Freezing Point, °C (°F) | Concentration dependent, typically −51.1 to 0.0 (−60.0 to 32.0) |
| Density at 20°C (68°F), g/ml (lb/gal) | Concentration dependent, typically 1.000–1.127 (8.35–9.40) |
| pH, 100% | 8.00–9.00 |
| Flash Point, °C (°F) | 120.5 (249.0), concentrate |
| Viscosity at 20°C (68°F), mPa·s | Concentration dependent, typically 3.9–16.6 |
| Vapor Pressure at 20°C (68°F), psia | Concentration dependent, typically 0.237–0.315 |
| Thermal Conductivity at 20°C (68°F), W/m·K | Concentration dependent, typically 0.331–0.457 |
| Specific Heat at 20°C (68°F), kJ/kg·K | Concentration dependent, typically 2.922–3.743 |
| Operating Temperature Range, °C (°F) | Concentration dependent, typically −51.0 to 121.0 (−59.8 to 249.8) |
| Volatile Organic Compounds (VOC), g/L | Concentration dependent |
| Acceptable Exposure Limit (AEL), ppm | 50 ppm (OSHA) |
Material Compatibility: Metals
| Material | Compatibility |
|---|---|
| Aluminum* | Compatible, Contact Technical Expert |
| Cast Steel | Compatible |
| Monel | Compatible |
| Brass | Compatible |
| Copper | Compatible |
| Nickel | Compatible |
| Bronze | Compatible |
| Hastelloy | Compatible |
| Stainless Steel | Compatible |
| Carbon Steel | Compatible |
| Inconel | Compatible |
| Tantalum | Compatible |
| Cast Iron | Compatible |
| Incoloy 825 | Compatible |
| Titanium | Compatible |
| Ti6Al4V | Compatible |
| Zinc** | Incompatible, Contact Technical Expert |
| Zinc Plating** | Incompatible, Contact Technical Expert |
| Galvanized Surfaces** | Incompatible, Contact Technical Expert |
| Magnesium** | Incompatible, Contact Technical Expert |
| Other Metals | Testing Recommended |
Material Compatibility: Gaskets & Polymers
| Material | Compatibility |
|---|---|
| Nitrile / NBR | Excellent to 65.6°C (150.0°F), Good Above 65.6°C (150.0°F) |
| Hydrogenated Nitrile / HNBR | Excellent |
| EP, EPDM | Excellent |
| Chloropropene | Fair |
| Isobutylene / IIR Latex | Good |
| Synthetic Isoprene / NR (Natural Rubber) | Good / Excellent |
| Natural Isoprene / NR (Natural Rubber) | Good / Excellent |
| Fluorosilicone | Contact Technical Expert |
| Fluorocarbon / FKM (Viton) | Good to 37.8°C (100.0°F), Poor Above 37.8°C (100.0°F) |
| Chemraz Kalrez / FFKM | Excellent |
| PTFE / FEP (Teflon) | Excellent |
| Gylon Stylve 3500, 3504, 3510 | Excellent |
| Nylon / Polyamide | Fair |
| Polyvinyl Chloride / PVC | Fair |
| Polyethylene | Excellent |
| Polypropylene | Excellent |
| Epoxy | Good / Excellent |
| Graphite | Excellent |
| Other Gaskets & Polymers | Testing Recommended |
Available Sizes
| Package Size | Net Weight |
|---|---|
| 275-gallon plastic totes | 2,587 lbs |
| 55-gallon plastic drums | 518 lbs |
| 5-gallon plastic pails | 47.0 lbs |
