Product Details

Specifications:

  • Primary Application: Heat transfer fluid
  • Water based: YES
  • Key ingredient: Potassium Formate
  • Specific Gravity (g/cm3): 1.341
  • Boiling Point: 118°C (244°F)
  • Freezing Point: -55°C (-67°F)
  • Lowest Op. Temp.: -51°C (-60°F)
  • System: Closed


Description:

NuTherm™ HC-50 is a high-performance heat transfer fluid designed as an alternative to less effective glycol, PAG, and Calcium Chloride open bath fluids. NuTherm HC-50 is non-toxic, non-flammable, and has a robust corrosion inhibition package making it ideal for use in closed systems down to -50°C (-58°F) and up to 218°C (425°F).

NuTherm HC-50 has superior thermophysical properties in comparison to traditional closed system heat transfer fluids, including higher thermal conductivity and specific heat, as well as lower viscosity, making it an extraordinarily more efficient closed system coolant within its operational temperature range. NuTherm HC-50 is non-hazardous, biodegradable, CFC-free, antimicrobial, and has exceptional thermal stability at high temperatures in comparison to glycols, PAG’s, Calcium Chloride, Trichloroethylene and Methylene Chloride (Dichloromethane) making it an intelligent alternative. NuTherm HC-50 is formulated with a incredibly robust and efficient corrosion inhibition package, allowing the product to be used on most metals including Stainless Steel, Carbon Steel, Cast Steel, Copper and its alloys (Brass & Bronze), Monel, Nickel, Hastelloy, Inconel, Tantalum, Titanium, Titanium alloys (Ti6Al4V), Aluminium and Cast Iron. Do not use on Zinc, Zinc-plated or galvanized metals, Magnesium. NuTherm HC-50 corrosion tests at 80°C show incredible results of x mmpy (x mpy) on C260 Brass alloys, x mmpy (x mpy) on 304L Stainless Steel, and x mmpy (x mpy) on AL1100 Aluminium. NuThem HC-50 does not produce pitting corrosion on Aluminium alloys like other Potassium Formate open bath heat transfer fluids.
*mmpy = millimeters per year; mpy = mils per year (1 mil = 0.001 inch); In general, uniform corrosion rates less than 2 mpy are acceptable for most applications. Corrosion rates between 2 and 10 mpy are considered marginal and may impact useful life of the equipment. Corrosion rates greater than 10 Mils per year are unacceptable.


Features

To the best of our knowledge, this product is California Prop 65 compliant.



NuTherm HC-50
BULK DENSITY 11.19 #/gal
SPECIFIC GRAVITY @ 20°C 1.341 g/cm³
TEMPERATURE RANGE (CLOSED SYSTEM) -51 to 110°C (-60 to 230°F)
THERMAL STABILITY HIGH
ODOR ODORLESS
FLASH POINT (°C) NONE
FIRE POINT (°C) NONE
MELTING POINT / FREEZING POINT   -55°C (-67°F)
BOILING POINT   118°C (244°F)
pH    8.0 to 8.5
APPEARANCE and COLOR    CLEAR, COLORLESS to AMBER



Temperature (°F) Viscosity (cPs) Thermal Conductivity (BTU/hr•ft•°F) Specific Heat (BTU/lb•°F) Density (lb/ft3)
-58 38.40 0.256 0.612 85.9
-50 28.30 0.258 0.615 85.7
-40 20.40 0.262 0.617 85.6
-20 11.90 0.268 0.622 85.2
0 7.70 0.275 0.628 84.8
20 5.40 0.281 0.633 84.4
40 4.20 0.288 0.638 84.0
60 3.40 0.294 0.643 83.6
80 2.90 0.301 0.649 83.3
100 2.40 0.307 0.654 82.9
120 2.10 0.314 0.659 82.5
140 1.80 0.320 0.664 82.1
160 1.60 0.327 0.669 81.7
180 1.40 0.333 0.675 81.3
200 1.30 0.340 0.680 80.9
220 1.20 0.346 0.685 80.6
240 1.10 0.353 0.690 80.2
260 0.97 0.356 0.696 79.8
280 0.89 0.366 0.701 79.4
300 0.82 0.373 0.706 79.0
320 0.76 0.379 0.711 78.6
340 0.70 0.386 0.717 78.3
360 0.65 0.392 0.722 77.9
380 0.61 0.399 0.727 77.5
400 0.57 0.405 0.732 77.1
420 0.53 0.412 0.737 76.7
425 0.53 0.413 0.739 76.6



Temperature (°C) Viscosity (mPa•s) Thermal Conductivity (W/m•K) Specific Heat (kJ/kg•K) Density (kg/m3)
-50 38.40 0.435 2.563 1378
-40 20.40 0.445 2.583 1373
-30 12.50 0.455 2.602 1367
-20 8.40 0.465 2.622 1362
-10 5.99 0.475 2.642 1356
0 4.70 0.485 2.661 1351
10 3.80 0.495 2.681 1345
20 3.20 0.505 2.701 1340
30 2.70 0.515 2.720 1334
40 2.40 0.525 2.740 1328
50 2.10 0.535 2.760 1323
60 1.80 0.545 2.780 1317
70 1.60 0.555 2.799 1312
80 1.50 0.565 2.819 1306
90 1.30 0.575 2.839 1301
100 1.20 0.585 2.858 1295
110 1.10 0.595 2.878 1290
120 1.00 0.605 2.898 1284
130 0.94 0.615 2.917 1279
140 0.87 0.625 2.937 1273
150 0.81 0.635 2.957 1267
160 0.76 0.645 2.977 1262
170 0.71 0.655 2.996 1256
180 0.66 0.665 3.016 1251
190 0.62 0.675 3.036 1245
200 0.58 0.685 3.055 1240
210 0.55 0.6945 3.075 1234


Vapor Pressure

Temperature (°C) Temperature (°F) Vapor Pressure (psia)
20 68 0.23
30 86 0.28
40 104 0.45
50 122 0.81
60 140 1.43
70 158 2.39
80 176 3.78
90 194 5.71
100 212 8.31
110 230 11.70
120 248 16.20



NuTherm™ HC-50 high-performance heat transfer fluid designed as an alternative to less effective glycol, PAG, and Calcium Chloride open bath fluids.
